Page 1. PRODUCTION & QUALITY CONTROL COMPOUND WEAVE BELT Manufacturing processes and project inspection PROVEN · STABLE · VERIFIED
Page 2. MANUFACTURER Manufacturing and project control Ningjin Yiyi Mesh Belt Co., Ltd. A manufacturer of metal conveyor belts and related conveyor components based in Ningjin, Shandong, China. Manufacturing experience since 1998. Current company established in 2008. Core belt forming, assembly, welding and inspection are managed in-house. Selected surface treatments and supporting components use external suppliers. YIYI MESH BELT manufacturing site
Page 3. ORDER CONTROL Approval and inspection sequence Stage Control point 01 Drawing approval Confirm dimensions, materials and equipment interfaces. 02 Trial production Inspect the first article before mass production. 03 Interface review Confirm weave construction and the selected drive arrangement. 04 Mass production Check formed components, assembly and weld condition. 05 Final inspection Inspect the finished belt before shipment. 06 Packing and records Confirm packing requirements and retain order records. Project drawings define the final configuration and inspection requirements.
Page 4. MATERIAL PREPARATION Stainless steel wire drawing In-house wire preparation Dedicated wire-drawing equipment supports the preparation of stainless steel wire for belt manufacture. Project requirement Confirm the material grade and wire diameter against the approved specification.
Page 5. MATERIAL PREPARATION Round-bar drawing In-house rod preparation Round-bar drawing is part of YIYI MESH BELT’s material preparation capability. Project requirement Rod material and diameter are selected for the belt design and approved drawing.
Page 6. MATERIAL CONTROL Material inspection equipment Alloy composition screening Tensile testing equipment Hardness testing equipment Confirm the applicable test method, acceptance criteria and required material records for each project.
Page 7. MATERIAL CONTROL Wire and rod diameter checks Wire diameter measurement Rod diameter measurement Check wire and rod diameters against the approved specification. Agree dimensions and tolerances in mm / in for the project.
Page 8. BELT PRODUCTION Spiral wire forming Spiral forming equipment Production workshop Wire is formed into spiral elements. Confirm the mesh geometry and wire dimensions before batch production.
Page 9. BELT PRODUCTION Compound Weave Belt forming equipment Belt forming equipment Production detail Form the belt to the selected spiral and rod arrangement. Construction is defined by the approved drawing.
Page 10. IN-PROCESS CONTROL Belt forming and geometry review Formed belt detail Production review Review formed belt geometry and surface arrangement during production.
Page 11. BEFORE MASS PRODUCTION Trial production and first-article inspection Customized orders undergo trial production and first-article inspection before mass production. Use approved drawings for acceptance dimensions and tolerances.
Page 12. FINAL QUALITY CONTROL Finished belt dimensional inspection Check finished belt dimensions against the approved specification. Measurement photographs show project examples, not universal belt dimensions.
Page 13. FINAL QUALITY CONTROL Surface condition inspection Belt surface detail Finished belt surface Inspect surface condition against the selected material and finish. Where treatment is specified, re-inspection follows treatment; selected treatments use external suppliers.
Page 14. FINAL QUALITY CONTROL Mesh construction inspection Mesh arrangement Construction detail Check the selected weave and rod arrangement against the approved drawing. Specify flat-wire dimensions separately where required.
Page 15. FINAL QUALITY CONTROL Edge finish inspection Edge construction detail Finished edge detail Inspect the selected edge construction for connection condition, consistency and burrs against the agreed requirements.
Page 16. PACKING & SHIPMENT Protective wrapping and wooden-case packing Protected belt roll End protection Wooden-case packing Protect the belt and confirm packing for the agreed transport route. Wooden-case fabrication uses external suppliers.
Page 17. TRACEABILITY Project records and repeat-order support Record Purpose for the buyer Approved drawing and revision Maintain the agreed specification for manufacture and reorders. Material and production records Support order traceability and review of manufacturing history. Inspection records and photographs Review recorded checks against the agreed requirements. Customer confirmations Retain technical decisions and approved changes. Agree the inspection documents you need before production. For replacement projects, include existing belt details, equipment geometry and operating conditions.
